Dual-Head Vegetable Cutter GA-VEG-077 | 300–1,000 kg/h
Price on Request
Dual-Head Cutting for Root and Leafy Vegetables
The GA-VEG-077 processes root and leafy vegetables simultaneously. Change cutting discs and adjust the conveyor and blade speeds to produce slices, shreds or dice.
Suitable Vegetables
Potatoes, sweet potatoes, melons and gourds, bamboo shoots, onions, eggplant, celery, Chinese cabbage, cabbage and spinach.
Technical Specifications
| Model | GA-VEG-077 |
|---|---|
| Overall dimensions | 1170 × 600 × 1190 mm |
| Machine weight | 135 kg |
| Cut length | 1–60 mm, adjustable |
| Reference capacity | 300–1000 kg/h |
| Power supply | 220 V single-phase |
| Motor ratings | 1 HP (root vegetables) + 1/2 HP (leafy vegetables) + 1/4 HP (conveyor) |
| Belt width | 120 mm |
| Output | Slices, shreds and dice |
Features and Included Cutting Accessories
- Both cutting heads can operate simultaneously.
- Adjustable conveyor and blade speeds.
- One large double-blade set.
- One dicing disc set.
- One slicing disc.
Capacity figures are references from the product catalogue. Actual results depend on the ingredients, tooling and feeding conditions.
Request a Quote or Cutting Test
Send us your vegetables, required output shape, cut size, target capacity, voltage and destination country. We can recommend a suitable blade configuration and prepare a quotation for your project.
